Microwave Products from TSL

TSL has developed a complete Series of RF and Microwave products for a variety of applications requiring Pulsed, CW, Linear, or Broadband capabilities.

Microwave Products from TSLProducts include amplifiers, transmitters, attenuators, and calibrators. Field Programmable Gate Arrays (FPGA) are used for applications requiring precise phase and modulation control. Most designs utilize state-of-the-art Gallium Nitride (GaN), Bipolar, and LDMOS components and can be supplied with or without an internal frequency source. TSL Microwave Products are in use worldwide by foreign, domestic, military, and civilian customers.

TSL Microwave Amplifier and Transmitter Products fall into the five Series indicated below. Maximum and minimum specifications for each Series are indicated. A more detailed breakdown for each Series is available.

Note that variations and combinations of capabilities are available. Please contact TSL for detailed specification or special requirements not listed.

TSL
Series
Amplifiers/
Transmitters
Frequency
(MHz)
Power
(Watts)
Duty
Cycle
(%)
Pulse
Width
(usec)
1100L-Band Airborne
(IFF, TCAS)
1030 and/or 10905–4,0001–100.5–35
1200L-Band Radar1200–140010–10,0000.1–201–1000
1400DME/TACAN960–121510–4,000IAW
standards
IAW
standards
1500S-Band2300–350010–5,0000.1–100.1–10
1600Broadband LinearDC–50005–100N/AN/A
1900Special ProductsSee spec
sheets
See spec
sheets
See spec
sheets
See spec
sheets
